Dual-Station Core Mold Vibration Equipment
This equipment integrates mechanical, electrical, hydraulic, and automatic control technologies. It can produce concrete drainage pipes with various joint forms, featuring high production automation, high production efficiency, and a unique production process. Vertical production completely solves the technical problem of collapse prone to occur in horizontal production of annular hollow structures, making it suitable for the production of large-caliber or extra-large-caliber pipes.
The transmission bearings of important parts such as vibrators adopt original imported SKF bearings, and the bearings of relevant parts of the whole machine adopt products from three well-known domestic enterprises.
Suitable for manufacturing large cement pipes
Equipment Models:
XM1000-2400*2-3Mï¼›XM1200-3000*2-3Mï¼›XM1500-4000*2-3M
XM1000-2400*2-3M
|
Pipe Fabrication Range |
1000–2400 mm (Dual-Station Configuration) |
|
Pipe Fabrication Length |
2–3 m (customizable per customer specifications) |
|
Main Motor Power |
30kw*4 |
|
Large Material Distributing Motor Power |
3kw |
|
Small Material Distributing Motor Power |
3kw |
|
Station Conversion Motor Power |
2.2kw |
|
Hydraulic Pump Station Power |
11kw |
|
Gantry Travel Motor Power |
2kw*2 |
|
Cooling Pump Station Power |
8kw |
|
Material Distributing Rotary Motor Power |
2.2kw |
|
Small Material Distributing Feed Motor Power |
1.5kw |
XM1200-3000*2-3M
|
Pipe Fabrication Range |
1200–3000 mm (Dual-Station Configuration) |
|
Pipe Fabrication Length |
2–3 m (customizable per customer specifications) |
|
Main Motor Power |
30kw*4 |
|
Large Material Distributing Motor Power |
3kw |
|
Small Material Distributing Motor Power |
3kw |
|
Station Conversion Motor Power |
2.2kw |
|
Hydraulic Pump Station Power |
11kw |
|
Gantry Travel Motor Power |
2kw*2 |
|
Gantry Travel Motor Power |
8kw |
|
Material Distributing Rotary Motor Power |
2.2kw |
|
Material Distributing Rotary Motor Power |
2.2kw |
|
Small Material Distributing Feed Motor Power |
1.5kw |
XM1500-4000*2-3M
|
Pipe Fabrication Range |
1500–4000 mm (Dual-Station Configuration) |
|
Pipe Fabrication Length |
2–3 m (customizable per customer specifications) |
|
Main Motor Power |
45kw*4 |
|
Large Material Distributing Motor Power |
3kw |
|
Small Material Distributing Motor Power |
3kw |
|
Station Conversion Motor Power |
2.2kw |
|
Hydraulic Pump Station Power |
11kw |
|
Gantry Travel Motor Power |
2kw*2 |
|
Cooling Pump Station Power |
8kw |
|
Material Distributing Rotary Motor Power |
2.2kw |
|
Small Material Distributing Feed Motor Power |
1.5kw |
