Fertbearing is thrust ball bearing with spherical seat factory.
A thrust ball bearing with a spherical seating surface, is a type of bearing designed to accommodate misalignment and axial loads. The bearing has a spherical seating surface on the housing washer, which allows for some angular misalignment between the shaft and the housing. This feature is particularly useful in applications where there may be shaft deflection or misalignment.
Fertbearing single thrust ball bearing with spherical housing seat advantages
A single thrust ball bearing with a spherical housing seat offers several advantages:
1. Misalignment compensation: The spherical housing seat allows the bearing to accommodate misalignment between the shaft and the housing. This is particularly useful in applications where there may be shaft deflection or misalignment during operation, reducing stress on the bearing and increasing its service life.
2. Increased load carrying capacity: The spherical housing seat design can distribute the load more evenly across the bearing, allowing it to handle higher axial loads compared to bearings with flat seating surfaces.
3. Reduced friction: The spherical seating surface can help reduce friction and wear, leading to improved efficiency and longer bearing life.
4. Versatility: The ability to accommodate misalignment makes these bearings versatile and suitable for a wide range of applications, including those with dynamic operating conditions.
5. Simplified installation: The spherical housing seat design can make installation easier, as it provides some forgiveness for misalignment during the mounting process.
These advantages make single thrust ball bearings with spherical housing seats well-suited for applications where misalignment, high axial loads, and efficient operation are important considerations.
Fertbearing thrust bearings with spherical seat washer application
Thrust bearings with spherical seat washers are commonly used in applications where there is a need to accommodate misalignment between the shaft and the housing. The spherical seat washer allows the bearing to adjust to angular misalignment, which can occur due to shaft deflection, mounting errors, or other factors. Here are some typical applications for thrust bearings with spherical seat washers:
1. Agricultural Machinery: In agricultural equipment such as tractors and combines, where dynamic misalignment can occur during operation, thrust bearings with spherical seat washers are used to handle axial loads and compensate for misalignment.
2. Mining Equipment: Mining machinery often operates in harsh conditions, and the ability of thrust bearings with spherical seat washers to accommodate misalignment makes them suitable for use in this industry.
3. Construction Machinery: Equipment used in construction, such as cranes and excavators, may experience misalignment due to the nature of their operation. Thrust bearings with spherical seat washers can help maintain proper alignment and support axial loads in these applications.
4. Industrial Gearboxes: Thrust bearings with spherical seat washers are used in industrial gearboxes where there may be misalignment between the gears and shafts, especially in applications with heavy loads and high speeds.
5.Marine Applications: In marine environments, where equipment is subjected to dynamic forces and vibrations, thrust bearings with spherical seat washers can help compensate for misalignment and support axial loads in marine propulsion systems and other equipment.
Fertbearing thrust ball bearing with spherical seat FAQ
1. Can thrust ball bearings with a spherical seat handle high axial loads?
Answer: Yes, thrust ball bearings with a spherical seat are designed to handle high axial loads. The design of the bearing and the arrangement of the balls allow for effective load distribution, making them ideal for applications requiring high load carrying capacity.
2. Are single thrust ball bearings with a spherical housing seat self-aligning?
Answer: Yes, these bearings have a degree of self-aligning capability. The spherical housing seat allows for slight misalignments between the shaft and the housing, improving the overall performance and reducing stress on the bearing components.
3. What are the differences between single thrust ball bearings with a spherical housing seat and other types of thrust bearings?
Answer: Single thrust ball bearings with a spherical housing seat offer the advantage of self-alignment, whereas other types of thrust bearings, such as cylindrical roller thrust bearings or tapered roller thrust bearings, may not have this feature. Additionally, single thrust ball bearings with a spherical housing seat are typically more suitable for high-speed applications due to their lower friction coefficient.
Product specifications
| Bearing No. | Dimensions(mm) | Weight(Kg) | |||
| d | D | D1 | H | ||
| 53200U | 10 | 26 | 28 | 13 | 0.036 |
| 53201U | 12 | 28 | 30 | 13 | 0.039 |
| 53202U | 15 | 32 | 35 | 15 | 0.042 |
| 53203U | 17 | 35 | 38 | 15 | 0.065 |
| 53204U | 20 | 40 | 42 | 17 | 0.095 |
| 53205U | 25 | 47 | 50 | 19 | 0.153 |
| 53206U | 30 | 52 | 55 | 20 | 0.186 |
| 53207U | 35 | 62 | 65 | 22 | 0.292 |
| 53208U | 40 | 68 | 72 | 23 | 0.353 |
| 53209U | 45 | 73 | 78 | 24 | 0.419 |
| 53210U | 50 | 78 | 82 | 26 | 0.504 |
| 53211U | 55 | 90 | 95 | 30 | 0.819 |
| 53212U | 60 | 95 | 100 | 31 | 0.897 |
| 53213U | 65 | 100 | 105 | 32 | 0.93 |
| 53214U | 70 | 105 | 110 | 32 | 0.96 |
| 53215U | 75 | 110 | 115 | 32 | 1.15 |
| 53305U | 25 | 52 | 55 | 22 | 0.205 |
| 53306U | 30 | 60 | 62 | 25 | 0.326 |
| 53307U | 35 | 68 | 72 | 28 | 0.475 |
| 53308U | 40 | 78 | 82 | 31 | 0.704 |
| 53309U | 45 | 85 | 90 | 33 | 0.888 |
| 53310U | 50 | 95 | 100 | 37 | 1.19 |
| 53311U | 55 | 105 | 110 | 42 | 1.78 |
| 53312U | 60 | 110 | 115 | 42 | 1.83 |
| 53313U | 65 | 115 | 120 | 43 | 2.04 |
| 53314U | 70 | 125 | 130 | 48 | 2.64 |
| 53315U | 75 | 135 | 140 | 52 | 3.42 |
We specialize in manufacturing all kinds of thrust ball bearing, focus on development and production of high performance, long life, single direction thrust ball bearing, double direction thrust ball bearing, thrust ball bearing with spherical seat, miniature thrust ball bearing, stainless thrust ball bearing etc. Our production range from diameter 3mm~300mm, precision could reach to P5.
Our products are widely used in railway, automobile, cleaning machine, compressor and steering machine. Depending on the comprehensive power of production, sales, development and technology, we will meet customers' requirements by quality and reliability. Our bearings are sold to European and Asia markets.
Why choose us?
Advantage:
Strong design ability, quick response, consistent quality for each shipment.
Package:
Roll with anti-rust paper + carton .
All package materials been used with high quality, could be storaged for long time and for long-distance sea shipment.
Lead time:
15~45 days depend on material situation and stock
Quality Guarantee:
Strictly control on quality, based on drawings , contracts and approved samples .
When customer feedback quality problems, respond positively and submit 8D report if necessary.
