Clamping Cylinder (Bolt Type)

The clamping cylinder provides the clamping force. Due to the size of the model, the span of the cylinder diameter is relatively large, and the cylinder with a large cylinder diameter is produced by casting.

The clamping cylinder provides the clamping force. Due to the size of the
model, the span of the cylinder diameter is relatively large, and the cylinder
with a large cylinder diameter is produced by casting.

Cylinder name Bore range Travel range Rated pressure (Mpa) Installation method
Clamping cylinder (bolt type) 45~300 200~2000 twenty one Flange

1. Tie rod type, the front and rear covers are fixed by a tie rod. Limited by
the tie rod, it is generally suitable for small oil cylinders. Although the wall
thickness is the thinnest, under the same specification, the external dimensions
will be too large, and the space waste is serious.

2. Bolt type, the front and rear covers and the cylinder barrel are connected
by bolt groups. The required thickness of the cylinder is the largest, and the
raw materials are relatively wasteful. Generally suitable for large
cylinders.

3. Threaded type, the front and rear covers and the cylinder barrel have
large threads, and are connected by threads. The required thickness is smaller
than the bolt type, but it is still thicker, and a large nut is required to
ensure the assembly direction. Generally suitable for large long cylinders

4. Welding type, the back cover and the cylinder are welded into a whole, the
wall thickness of the cylinder is relatively thin, and the whole is relatively
compact. The material cost is not high, but the processing is the most difficult
and the processing cost is the highest.
