PRODUCT INTRODUCTION
QUALITY ASSURANCE / LONG WARRANTY/ WORRY-FREE OPERATION
-
Product Name: IR RACEWAY SUPERFINISHING MACHINE FOR TRB
-
Advantage: APPLICABLE FOR THE INNER RING RACEWAY SUPERFINISHING OF TRP
-
Features: PROCESSING RANGE: MAXIMUM OUTER DIAMETER OF THE OUTER RING RACEWAY: Φ100MM; WORK PACE:6-11S; SMALL FOOTPRINT; CHANGEOVER TIME:≤0.5H
BUSBAR SHAPE BEFORE & AFTER SUPERFINISHING
INTELLIGENT GREEN MANUFACTURE
OUTER RING RACEWAY
INNER RING RACEWAY
FLANGE
PRODUCT ADVANTAGES AND DESCRIPTION
| ADVANTAGE | DESCRIPTION |
| OIL STONE (WIDE) | CUSTOMIZED SPECIFICATIONS OF THE OIL STONE ACCORDING TO THE SIZE OF THE RACEWAY SURFACE TO ENSURE A ONE-TIME SUPERGRINDING FOR THE WHOLE SURFACE; ENHANCED UNMANNED EFFICIENCY BY LONG SERVICE TIME (ABOUT 4000PCS / REPLACEMENT); AUTOMATIC COMPENSATION AND LIMIT ALARM. |
| FLANGE OIL STONE | CONVENIENT TO USE AND REPLACE WITH A HIGHER UNMANNED EFFICIENCY USING THE CBN OIL STONE (REPLACEMENT FREQUENCY: 5000PCS/ REPLACEMENT). |
| REPLACEMENT / MAINTENANCE | THE CHANGEOVER TIME OF 30 MINUTES; ONE-PIECE QUICK CHANGE OF THE EXTERNAL ADJUSTMENT WITH LOW DEPENDENCE ON TECHNOLOGY. LOW MAINTENANCE COST; GUARANTEED AIR SUPPLY QUALITY THROUGH THE POSITIVE-PRESSURE OPERATION OF AIR BEARING. |
| POSITION MEMORY | PRESERVED DIFFERENT MODELS, INCLUDING ANGLE, POSITION, AND HEIGHT PARAMETERS; AVAILABLE DIRECTLY FOR CHANGEOVER; AUTOMATIC ROTATION AND DATA SETTING FOR DATA ADJUSTMENT, AND NO NEED OF A WRENCH. |
| EXTERNAL DIMENSION | SINGLE-STATION COMPOUND OPERATION OF THE WHOLE MACHINE; SMALL SIZE AND SMALL FOOTPRINT; ABOUT ONLY 2.5 TONS; SIMPLE INSTALLATION AND LOCATION. |
| ASSEMBLY QUALITY | RACEWAY / FLANGE ROUGHNESS: RA≤0.06, WHICH CAN EFFECTIVELY ENHANCE THE NOISE DETECTION EFFECT (DU LEVEL). ROUNDNESS REPAIR DEGREE OF 30% AND GUARANTEED CONVEXITY. |
